This 4.3″ LCD mirror monitor replaces the vehicle reversing mirror and can be connected to either one or two rear view cameras. You can switch between the two cameras by either pressing the ‘cam select’ button on the monitor, or it can be wired to switch between cameras automatically when you select reverse gear.
This monitor can operate on 12 V or 24 V vehicles, with a high and low voltage protection and also short circuit protection. The mirror surface has also been treated with an anti-glare process to improve night vision.
4.3″ Rear Mirror Monitor
Built-in control box
Wide view angle: (up/down): 25/45, (left/right): 45/45
Brightness (cd/m2): 200
Contrast ratio: 400:1
Resolution: 320 3*(RGB)*234 (pixels)
Colour system: PAL/NTSC
Power requirement: 12/24 V DC
Power consumption: 48 dB
Operating temperature range: -30C to + 70C
Storage temperature range: -40C to + 80C
Dimension (L x W x H): 133.4 x 75 x 204
Vibration resistance: 10G
